Exports Modification¶

LIEF provides extensive support for modifying the PE export table, enabling you to add, remove, or modify export entries, or create an entire export table for a PE binary.

This functionality requires enabling , as the modified export table is relocated to a new section. The section name can be controlled with .

Creating Export Entries¶

Creating a is useful for exposing a “hidden” function by its address, allowing it to be used like a standard linker-generated export.

This could be used for code lifting or fuzzing.

pe: lief.PE.Binary

exp = pe.get_export()
assert isinstance(exp, lief.PE.Export)

# Remove an entry
exp.remove_entry("my_exported_name")

# Add a new export
exp.add_entry("fuzz_me", 0x10010)

config = lief.PE.Builder.config_t()
config.exports = True
config.export_section = ".myedata"  # optional

pe.write("out.dll", config)

std::unique_ptr<LIEF::PE::Binary> pe;

LIEF::PE::Export* exp = pe->get_export();

// Remove an entry
exp->remove_entry("my_exported_name");

// Add a new export
exp->add_entry("fuzz_me", 0x10010);

LIEF::PE::Builder::config_t config;
config.exports = true;
config.export_section = ".myedata";

pe->write("out.dll", config);

let pe: &mut lief::pe::Binary = some_pe;

let mut exp: lief::pe::Export = pe.export().unwrap();

// Remove an entry
exp.remove_entry_by_name("my_exported_name");

// Add a new export
exp.add_entry_by_name("fuzz_me", 0x10010);

let mut config = lief::pe::builder::Config::default();
config.exports = true;
config.export_section = ".myedata".to_string();

pe.write_with_config("out.dll", config);

Creating an Export Table¶

This section introduces the API for creating an export table. We’ll explore a scenario where we want to convert a PE executable into a DLL.

Note

The process of converting an executable to a library is also detailed for ELF binaries in the tutorial: 08 - Transforming an ELF executable into a library.

First, we must update the PE headers to ensure they are compliant with the DLL format:

pe: lief.PE.Binary

pe.header.add_characteristic(lief.PE.Header.CHARACTERISTICS.DLL)
pe.optional_header.addressof_entrypoint = 0

std::unique_ptr<LIEF::PE::Binary> pe;

pe->header().add_characteristic(LIEF::PE::Header::CHARACTERISTICS::DLL);
pe->optional_header().addressof_entrypoint(0);

let pe: &mut lief::pe::Binary = some_pe;

pe.header()
    .add_characteristic(lief::pe::headers::Characteristics::DLL);
pe.optional_header().set_addressof_entrypoint(0);

Then, we can start creating and populating a new export table:

pe: lief.PE.Binary

exp = lief.PE.Export(
    "lib_exe2dll.dll",
    [
        lief.PE.ExportEntry("cbk1", 0x0001000),
        lief.PE.ExportEntry("cbk2", 0x0001010),
    ],
)

pe.set_export(exp)

config = lief.PE.Builder.config_t()
config.exports = True

pe.write("lib_exe2dll.dll")

std::unique_ptr<LIEF::PE::Binary> pe;

LIEF::PE::Export exp("lib_exe2dll.dll",
                     {
                         LIEF::PE::ExportEntry("cbk1", 0x0001000),
                         LIEF::PE::ExportEntry("cbk2", 0x0001010),
                     });

pe->set_export(exp);

LIEF::PE::Builder::config_t config;
config.exports = true;

pe->write("lib_exe2dll.dll", config);

let pe: &mut lief::pe::Binary = some_pe;

let mut exp = lief::pe::Export::new();

exp.set_name("lib_exe2dll.dll");
exp.add_entry_by_name("cbk1", 0x0001000);
exp.add_entry_by_name("cbk2", 0x0001010);

pe.set_export(&exp);

let mut config = lief::pe::builder::Config::default();
config.exports = true;

pe.write_with_config("lib_exe2dll.dll", config);

Limitations

This binary-to-library example assumes that the original executable was compiled to be position-independent, meaning it contains relocations.

Within a Python environment, we can verify that lib_exe2dll.dll can be loaded as a DLL and that we can call cbk1 and cbk2:

import ctypes

lib = ctypes.windll.LoadLibrary("lib_exe2dll.dll")

assert lib.cbk1() >= 0
assert lib.cbk2() >= 0
